15A Power Conditioner and Distribution Unit

ETA-C15D

    The ETA-C15D is been designed to meet most installation requirements for AC power distribution and equipment power protection. The 15A compact 1RU unit AC Mains Voltage can be monitored via the front panel from the precision Digital Volt Meter. To light your rack, the ETA-C15D has incorporated a front panel pull-out dimmable LED tube light. The rear of the rack can be illuminated by the optional 16" gooseneck LED lamp connected via an XLR style socket (AP-GNL18).

    The ETA-C15D features noise filtering for eliminating unwanted Radio Frequency Interference (RFI) that can be introduced into the AC lines by nearby radio transmitters or wireless products. EMI filters are also incorporated to reduce noise from Electromagnetic Interference (EMI) generated by items such as electric motors and switching power supplies.

    The Abnormal Voltage indicator on the front panel will flash if the AC Mains is between 101VAC and 107VAC or 128VAC and 132VAC. This is to inform you that a surge occurred and may have damaged voltage sensitive equipment. If an extreme voltage swing occurs above 132VAC or below 101VAC, the ETA-C15D Extreme Voltage Shutdown (EVS) protection circuit will automatically activate and turn all outlets off until it is manually reset. The ETA-C15D offers intelligent power management control, along with noise filtering and spike/surge protection making it the most compact, effective power management protection system on the market today.

    Features
    10 Total Outlets
    8 Rear Panel Outlets: 6 Filtered and Switched, 1 Filtered, and 1 Unswitched
    2 Front Panel, Unswitched Outlets
    Radio Frequency and Electromagnetic Interference Filtering
    Dual Clamping Spike & Surge Suppression, DCS Circuitry
    Front Panel Digital AC Mains Voltmeter
    Abnormal AC Line Voltage Indicator
    Extreme Voltage Shutdown (EVS) Below 101V or Above 132V AC Line
    Circuit Breaker Protection @ 15A
    Front Mounted Pull-Out LED Light with 2-Position Dimmer
    Rear Mounted XLR Connector for 12VDC LED Lamp (AP-GNL18)
    Tech Specs
    Current Rating 15 Amps
    Operating Voltage 102-132VAC
    Minimum Spike Clamping Voltage 460 VRMS @ 3000A
    Maximum Spike Clamping Voltage 6000V
    Power Consumption 12 Watts
    Height 1.75" (44.5mm)
    Width 19" (482.6mm)
    Depth 8.5" (219.5mm)
    Certifications MET (UL 1449)
    Support Files
    Data Sheet Reference Chart (1 page) View | Download
    Data Sheet Data Sheet (2 pages) View | Download
    Owners Manual Owners Manual (12 pages) View | Download
